Smart Gate Driver BLDC Motor Control based on Renesas Solution

The RAA227063 is a smart gate driver IC for 3-phase senseless brushless DC (BLDC) motor applications. It integrates three half-bridge smart gate drivers that are capable of driving up to three N-Channel MOSFET bridges and supports bridge voltages from 4.5V to 60V, with 1A drive and 2A sinking current capability. It is equipped with an LDO that is fed directly from the input voltage, providing power to the MCU.
